Malleable iron, used for the connection of polyethylene pipe to steel pipe where a screwed end is available. Malleable iron, using Flexgrip rubber joints and appropriate inserts for the rapid connection of polyethylene pipes. Part numbers shown opposite are for fittings without anti-shear sleeve retention nuts. If anti-shear nuts are required on R to PE fittings please contact Sales Office +44 (0)1473 277300. Finish = Hot Dipped Galvanized (unless otherwise stated) * Finish = Uncoated

Part No. Size (Pipe x Thread) For Use With Pipe
CG0010 R1" x 1" Locking Gas Steel
CG0045 R1" x 1" Locking Gas Steel
CG0001* R1.1/4" x 1/1/4" Locking Gas Steel
CG0003* R1.1/2" x 1.1/2" Locking Gas Steel
CG0046 R2" x 2" Locking Gas Steel
CG0020 R3/4" x 25mm SDR11 Locking Gas PE80
